TG452B

Battery Backed Edge Gateway

TG452B is a rugged, programmable industrial edge gateway equipped with an integrated 18650
rechargeable Li-ion backup battery slot. Designed to eliminate data loss during power outages,
it bridges field sensors, meters, and controllers to cloud platforms with seamless 4G/5G RedCap
cellular failover and rich protocol translation.

Buy Now

科技风产品图片展示

1 / 1

TG452B Battery Backed Edge Gateway

" Stay connected. Keep monitoring Keep your data protected. "

Features

·4G LTE, or 5G RedCap (Optional), Dual SIM
·2-ETH, 1-RS232, 2-RS485, 2-DI, 6-ADC, 3-Relay, 1-TF Slot, 1-CAN*, 2-DC Power Output, 2.4G WIFI, GNSS
·18650, 3.7V Li-ion Battery slot for power backup
·Programming Bivocom OS: C/C++, Python, Node-RED, Ubuntu*, Docker*
·Modbus RTU/TCP, JSON, BACnet IP/MSTP*, OPC UA*, IEC 101/104/61850*, DNP3* and customized industrial protocols
·MQTT, FTP*, HTTP(S), Wireguard, Tailscale*, SNMP*, Telnet, SSH

Certifications

Lifetime Guarantee

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Learn More

On-site Service

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Learn More

On-site Service

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Learn More

24/7 Support

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Learn More

How TG452B Works in Your IIoT System

TG452B collects raw signals from field devices, executes local edge logic, stores data locally on TF‑card, then forwards standardized data to on‑premise SCADA or Bivocom DMP / third‑party cloud platforms via cellular / Ethernet / Wi‑Fi uplink.

Backup battery ensures continuity during power blackouts.

TG452 Battery-Backed Edge Gateway Bivocom

Heading

Panel

Heading

Systems

CPU

32-bit ARM Cortex A7

Flash

1GB (8GB Optional)

RAM

256MB (512MB Optional)

Cellular

Antenna

2 x 50 Ω SMA-K

SIM Slot

2 Mini SIM (2FF)

Ethernet

Ports

2 x 10/100 Mbps

1 x WAN, 1 x LAN, or 2 x LAN Configurable

Serial

Ports

1 x RS232, 2 x RS485

Baud Rate

1200bps to 230400bps

I/O

Digital Input

2-DI (Isolation, Dry contact), Optional Wet contact (Status "1": 0-3V, Status "0": 5-30V)

Relay Output

3-Relay (COM+NO+NC, Up to 5A, 30VDC/250VAC switch)

Analog Input

6 x 12-bit (4-20mA/0-5V Configurable)

CAN (Optional)

1, CAN2.0B, SAE J1939*

Power Output*

1 x 12VDC/1A and 1 x 5VDC/1A for powering field sensors & devices

Note: Disabled on battery mode

Wi-Fi

Antenna

1 x 50 Ω RP-SMA-J

Standard

IEEE 802.11b/g/n, AP/Client modes

Bands

2.4GHz

Security

Open, WPA, WPA2, Radius

GNSS

Module

GNSS from cellular module

Antenna

1 x 50 Ω SMA-J

External Storage

TF Slot

1 x Micro SD slot, Up to 32GB

Usage

User Program and Data Storage

Power

Input

5-60VDC

Standard Power

12VDC/1.5A

Idle Mode*

220～265mA@12VDC

Working Mode*

280～330mA@12VDC

Backup Battery*

1 × 18650, 3.7 V Li-ion

Note: Battery not included; sold separately.

Software

Programming

Bivocom OS (OpenWrt based Linux OS, Or Optional Ubuntu OS)

C/C++, Python, Node-RED, Docker(Ubuntu)*, LUA* and SDK

Data Protocols

Modbus RTU/TCP, SMS, SNMP*, IEC101/104*, IEC61850*, DNP3*, BACnet IP/MSTP*, OPC UA*, etc.

Network Protocols

VXLAN, GNSS, IPV6*, DDNS, DNS, ARP, Static Routing, NAT, Firewall, Telnet/SSH, PPP, PPPoE, DHCP, ICMP, NTP, etc.

Server Supported

MQTT, HTTP(S), Transparent TCP/UDP, FTP*

VPN

Wireguard/OpenVPN/IPsec/PPTP/L2TP/Tailscale*

Firewall

ACL/DMZ/Port Mapping/MAC Binding

Management

Web, CLI, SMS, Bivocom DMP (Device Management Platform)*

Reliability

Dual SIM*, WWAN and WAN Failover, Hardware & Software Watchdog

Physical Characteristics

IP Rating

IP30

Housing & Weight

Metal, 829g (1.83lbs), without accessories

Dimensions

143 x 114 x 55.10mm (5.63 x 4.49 x 2.17in)

Mounting

Desktop, DIN-Rail

Environmental

Operating Temp.

-35°C to +75°C (-31℉ to +167℉)

Storage Temp.

-40°C to +80°C (-40℉ to +176℉)

Relative Humidity

5% to 95% (non-condensing)

Others

Reset Button

LED Indicators

Power, WIFI, System, Alarm, Online, Signal

Built-in

Watchdog, RTC, Timer

Approvals

CE*, RCM*, FCC*

Warranty Period

Standard: 2-Year limited warranty

Extended: 3-5 Years

Data Sheet

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

User Guide

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Firmware

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Cras in finibus lorem. Aenean urna felis.

Package Contents

·TG452B x 1
·Cellular Antenna x 2
·WiFi Antenna x 1
·GNSS Antenna x 1
·Ethernet Cable x 1
·12-Pin Terminal Block x 2
·9-Pin Terminal Block x 1
·2-Pin Terminal Block x 1
·DIN-Rail Mount Kit x 1
·Power Adapter x 1
(Optional EU/UK/AU/US/CN Type)

Model

Part Number

Cellular

Frequency Bands

TG452B-LF

TG452B - L <1><2> - <3>

4G LTE

4G LTE CAT 4*

(Optional Global or Regional Version)

EMEA/Asia: B1/B3/B5/B7/B8/B20/B38/B40/B41
ANZ/LATAM: B1/B3/B5/B7/B8/B28
NA: B2/B4/B5/B12/B13/B14

TG452B-RC

TG452B - RC <1><2> - <3>

5G RedCap

5G NR Sub-6 SA*

(Optional Global or Regional Version)

5G NR: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/30/38/40/41/48/66/70/71/77/78/79
LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/30/66/70/71
LTE TDD: B34/38/39/40/41/42/43/48

Part Numbering Rules

<1>: 5G or 4G module for different countries and regions
<2>: DS = Dual SIM Single Module
<3>: W = 2.4G WIFI
GN = GNSS from cellular module

Note:

Region-specific cellular modules are available; consult Bivocom sales for details.
Compiler & SDK are provided for secondary development. Ubuntu require dedicated hardware&firmware (8GB Flash version)
DSSM: Dual-SIM single-module design with automatic network failover; DSDM: Dual-SIM dual-module design supporting load balancing.
Bivocom DMP (Device Management Platform) requires a license fee.
*Optional functions rely on matching hardware/firmware versions; not all features supported on one device.
Power consumption is measured under laboratory conditions and is for reference only.
Product doesn’t come with battery, it’s sold separately.
*Listed certifications are pending.
Extended warranty pricing varies.
Digital user manuals are free to download from Bivocom official website for environmental protection.
